Compact3588S

* 处理器: Rockchip RK3588S octa-core processor, 4x Cortex-A76 cores @ 2.4GHz + 4x Cortex-A55 cores @ 1.8GHz
* NPU: 6 TOPS
* 内存: 8GB/16GB
* 存储: 32GB/64GB/128GB/256GB
* 接口: USB3.0 Host, 3x USB2.0 Host, USB Type-C power, 2x MIPI CSI, MIPI DSI, 2x HDMI out, GbE, Micro SD, M.2(4G/SSD), Audio I/O, GPIO, etc.
* 操作系统: Android 14, Debian 12, Buildroot
* 尺寸: 85 x 56 mm
* 扩展模块: 4G, Camera, WiFi, 10.1-inch LCD

产品简介
硬件
软件
下载
订购
常见问题

Compact3588S搭载瑞芯微RK3588S八核64位处理器，采用4核Cortex-A76+4核Cortex-A55架构，搭配ARM Mali-G610 MP4 GPU与6TOPS算力NPU，轻松驾驭复杂算法与多任务处理，无论是8K超清视频渲染、多屏异构显示，还是AI模型推理，均以流畅体验重塑性能边界。

全能接口，无缝升级

延续树莓派4经典尺寸与接口布局，支持无缝硬件迁移。标配8GB LPDDR4x内存+32GB eMMC 5.1存储，支持最高16GB LPDDR4x内存和256GB eMMC存储，并配备M.2插槽（可选，与4G模块复用），可拓展高速固态硬盘，满足大数据量吞吐需求。板载HDMI 2.1、MIPI DSI/CSI、USB3.0等丰富接口，支持三屏异显（8K+4K+2K）与多摄像头接入，为工业控制、智能安防等场景提供灵活扩展能力。

智能视觉，触手可及

集成瑞芯微第四代编解码引擎，支持8K@60fps视频解码与8K@30fps编码，搭配NPU实现实时AI增强。无论是工业质检中的缺陷检测、零售场景的客流分析，还是机器人视觉导航，均可通过本地化AI处理实现毫秒级响应，数据隐私与效率兼得。

场景赋能，全面覆盖

边缘计算：轻量化部署，支持容器化应用与微服务架构
智能安防：多屏监控+AI行为分析，构建主动防御体系
工业控制：通过三屏异显实现多参数同步监控，提升运维效率
机器视觉：8K超清图像采集+NPU加速，赋能精密检测场景

Compact3588S VS Raspberry Pi 4
Model	Compact3588S	Raspberry Pi 4 Model B
Processor	Rockchip RK3588S, octa-core 64-bit SoC. 4x Cortex-A76 @ 2.4GHz + 4x Cortex-A55 @ 1.8GHz	Broadcom BCM2711, quad-core 64-bit SoC. 4x Cortex-A72 @ 1.5GHz
Lithography	8nm	28nm
GPU	ARM Mali-G610 MP4	Videocore-VI
NPU	6 TOPS	N/A
Memory	8GB/16GB LPDDR4X	1GB/2GB/4GB/8GB LPDDR4
Storage	- 32/64/128GB/256GB eMMC flash - M.2 PCIe 2.1 socket NVMe SSD - Micro SD slot	Micro SD slot
Connectivity	- 2.4GHz and 5GHz IEEE 802.11 a/b/g/n/ac/ax wireless LAN, Bluetooth 5.2 - Gigabit Ethernet	- 2.4GHz and 5GHz IEEE 802.11 b/g/n/ac wireless LAN, Bluetooth 5.0 - Gigabit Ethernet
Video & sound	- 2x HDMI (1x HDMI2.1, 1x DP1.4 to HDMI2.0) - MIPI DSI display port (4-lane) - 2x MIPI CSI camera port (1x 4-lane, 1x 2-lane) - stereo output and composite video port	- 2x HDMI2.0 - MIPI DSI display port (2-lane) - MIPI CSI camera port (2-lane) - stereo output and composite video port
Multimedia	- H.265/VP9/AVS2 decode (8Kp60); - H.265/H.264 encode (8Kp30); - OpenGL ES 1.1/2.0/3.2, OpenCL 2.2, Vulkan 1.2 - 48M ISP	- H.265 decode (4Kp60); - H.264 encode (1080p30); - OpenGL ES 3.1, Vulkan 1.0
USB	- 1x USB 3.0 ports - 3x USB 2.0 ports	- 2x USB 3.0 ports - 2x USB 2.0 ports
GPIO	Extended 40-pin GPIO header	Extended 40-pin GPIO header
Power in	- 5V DC via USB-C connector (minimum 3A) - 5V DC via GPIO header (minimum 3A) - Power over Ethernet (PoE)–enabled (requires separate PoE HAT)	- 5V DC via USB-C connector (minimum 3A) - 5V DC via GPIO header (minimum 3A) - Power over Ethernet (PoE)–enabled (requires separate PoE HAT)
Dimensions	85 x 56 mm	85 x 56 mm

规格参数
SoC		Rockchip RK3588S. 四核 Cortex-A76 + 四核 Cortex-A55
GPU		ARM Mali-G610 MP4. 支持 OpenGL ES 1.1/2.0/3.2, OpenCL 2.2, Vulkan 1.2
NPU		6 TOPS
内存		8GB 或16GB LPDDR4X
存储		32GB, 64GB,128GB 或 256GB eMMC flash MicroSD card 卡槽 M.2插槽 (与4G 模块复用)
电源		5V/3A DC (通过USB-C 或扩展GPIO供电 ) PoE (需扩展PoE模块)
USB		3x USB2.0 Host 1x USB3.0 Host/device
网络通信		千兆以太网 RJ45 接口。Realtek RTL8211F-CG controller 2.4G/5G 2T2R WiFi (802.11a/b/g/n/ac/ax) , Bluetooth5.2 可选4G LTE模块
调试接口		USB-C
Video	Output	HDMI 2.1, up to 8Kp60, Micro HDMI (HDMI0) DP1.4 to HDMI2.0, up to 4Kp60, Micro HDMI (HDMI1) MIPI DSI, up to 4Kp60, 30-pin FPC connector
Video	Input	2x MIPI-CSI for camera (Multiplexed with I2C) 4-lane camera via 30-pin FPC connector 2-lane camera via 24-pin FPC connector
Audio		3.5mm audio I/O jack
Key		Recovery
RTC		RTC), powered from external battery, 2-pin connector
扩展接口		2x I2C, 1x PWM, 2x UART, 1x CAN, 1x SPI and 12x GPIO via 40-pin GPIO header
重量		58 gram
尺寸		85 x 56 mm (Raspberry Pi 4 Model B form factor)
应用		IoT devices, Industrial monitoring equipment, smart home devices, smart cameras, and smart customer service robots, etc.

GPIO Header Pin Definition

Compact3588S-GPIO-definition

Pin	Signal	Pin	Signal	Pin	Signal	Pin	Signal
1	VCC_3V3_S0	11	UART3_RX_M2/ GPIO4_A6_d	21	SPI0_MISO_M2_3V3	31	CAN2_TX_M0/ GPIO3_C5_u
2	VDD5V	12	UART9_RX_M1/ GPIO4_B5_d	22	GPIO1_D0_d	32	GPIO3_C6_u
3	I2C3_SDA_M0_3V3	13	UART0_RX_M2/ GPIO4_A4_d	23	SPI0_CLK_M2_3V3	33	GPIO1_C6_d
4	VDD5V	14	GND	24	SPI0_CS0_M2_3V3	34	GND
5	I2C3_SCL_M0_3V3	15	UART0_TX_M2/ GPIO4_A3_d	25	GND	35	GPIO1_D5_d
6	GND	16	GPIO1_A2_d	26	SPI0_CS1_M2_3V3	36	GPIO3_B7_d
7	PWM11_IR_M3/ GPIO3_D5_d	17	VCC_3V3_S0	27	I2C7_SDA_M2/ GPIO3_D3_d	37	GPIO1_B0_u
8	UART7_TX_M1/ GPIO3_C0_d	18	GPIO1_A3_d	28	I2C7_SCL_M2/ GPIO3_D2_d	38	GPIO1_C2_d
9	GND	19	SPI0_MOSI_M2_3V3	29	CAN2_RX_M0/ GPIO3_C4_u	39	GND
10	UART7_RX_M1/ GPIO3_C1_d	20	GND	30	GND	40	GPIO4_A7_d

Block Diagram

Compact3588S block diagram

PCB Dimension

Compact3588S PCB dimension

OS	Item	Feature	Description
Android 14	Boot	U-Boot 2017.09	rk3588_spl_loader_v1.17.113.bin
	Kernel	Version	Linux 6.1.75
	Drivers	eMMC	eMMC5.1
		LCD&TP	10.1-inch MIPI LCD with touch screen, 800*1280
		HDMI	Support 8K, 4K, 1080P, 720P, 480P resolution
		DP-to-HDMI	Support 4K, 1080P, 720P, 480P resolution
		Audio	Headphone input/ output
		USB 2.0	3x USB 2.0 Host
		USB 3.0	Host/device
		Ethernet	10/100/1000 Mbps Ethernet
		Camera	MIPI camera. IMX415, OV13850
		4G	EM05
		WiFi	802.11 a/b/g/n/ac/ax . RTL8852BE
		Bluetooth	Bluetooth 5.2. RTL8852BE
		SD	Micro SD
		Serial Port	Debug, USB Type-C
		UART	2x UART, TTL
		RTC	Support
		SPI	Support
		Key	Recovery
	Compiler Environment	Ubuntu 22.04/openjdk 17.0.4.1
	Debug Tools	SecureCRT, AndroidTool.exe, ADB

OS	Item	Feature	Description
Debian 12 Buildroot (Linux 6.1)	Boot	U-Boot 2017.09	rk3588_spl_loader_v1.18.113.bin
	Kernel	Version	Linux 6.1.84
	Drivers	eMMC	eMMC5.1
		LCD	10.1-inch MIPI LCD with touch screen, 800*1280
		HDMI	Support 8K, 4K, 1080P, 720P, 480P resolution
		DP-to-HDMI	Support 4K, 1080P, 720P, 480P resolution
		Audio	Headphone input/ output
		USB 2.0	3x USB 2.0 Host
		USB 3.0	Host/device
		Ethernet	10/100/1000 Mbps Ethernet
		Camera	MIPI camera. IMX415, OV13850
		4G	EM05
		WiFi	802.11 a/b/g/n/ac/ax. RTL8852BE
		Bluetooth	Bluetooth 5.2. RTL8852BE
		SD	Micro SD
		Serial Port	Debug, USB Type-C
		UART	2x UART, TTL
		RTC	Support
		SPI	Support
		Key	Recovery
	Compiler Environment	Ubuntu 22.04
	Debug Tools	SecureCRT, AndroidTool.exe, ADB

Expansion Module	Module Detail	Android	Debian	Buildroot
4G	Quectel EM05 LTE Module. M.2 (NGFF) form factor	√	√	√
WiFi&Bluetooth	BL-M8852BP2 module. 2.4/5G WiFi + Bluetooth 5.2 (Onboard. Standard configuration)	√	√	√
Camera	SONY IMX415, 8.46-Megapixel	√	√	√
Camera	OV13850 module, 13-Megapixel	√	√	√
10.1-inch LCD	800 * 1280 Pixels. MIPI interface	√	√	√
