1. Overview
1.1 Summary
EM1126B-P is a single board computer (SBC) powered by Rockchip RV1126B-P AI SoC. It integrates a quad-core Cortex-A53 processor and a 3TOPS NPU, specifically designed for edge AI computing, video analytics, and image recognition applications. With a built-in multi-channel AI-ISP image processing engine, H.264/H.265 codec, and a rich set of multimedia and peripheral interfaces, EM1126B-P supports MIPI camera inputs and 1080P display output. It is widely applicable to smart cameras, AI edge boxes, security surveillance, industrial vision, and more.
1.2 Product Parameters
Specifications |
|
|---|---|
CPU |
Rockchip RV1126B-P. Quad-core Cortex-A53 @ 1.6GHz |
NPU |
3 TOPS |
Memory |
2GB/4GB LPDDR4 |
Storage |
8GB/16GB/32GB/64GB/128GB/256GB eMMC Micro SD card slot |
Power Supply |
12V/3A DC input jack 7.4V Li-Battery |
USB |
1x USB2.0 OTG 4x USB2.0 Host 2.0 |
Connectivity |
Gigabit Ethernet RJ45 portvia Realtek RTL8211F-CG controller 2.4G WiFi (802.11b/g/n) with Bluetooth 4.2 |
Serial Port |
1x Serial port for debug, 3-pin connector 1x UART, 6-pin connector 1x RS485, 3-pin connector |
Display |
MIPI DSI, 26-pin header |
Audio |
Rockchip RK809-9 audio codec. 3.5mm Audio out jack 2-channel Speaker (4-pin connector) 1x digital MEMS MIC, 1x differential MIC |
Camera |
2x MIPI Cameras, 24-pin FPC connector |
Keys |
Recovery, Power |
Other features |
RTC with battery connector, GPIO, SPI, I2S, ADC, CAN, IR |
Dimensions |
Based board – 120 x 95mm; CPU module - 38 x 30mm |
